Deli DL4161-2 Horizontal Instrument Bracket – Aluminium Laser Level Tripod Stand 0.45–1.2m (5/8" Mount)
Deli DL4161-2 Horizontal Instrument Bracket – Aluminium Laser Level Tripod Stand 0.45–1.2m (5/8" Mount)
A lightweight, rigid aluminium alloy stand that lifts your laser level or line laser to the exact working height you need – from 0.45 m for skirting and floor tiling up to 1.2 m for wall tiling, partitions and gypsum work. Available now at Shabbiri Hardware, Magadi Road – Ongata Rongai and Tuala.
Product Overview
The Deli DL4161-2 Horizontal Instrument Bracket is a professional laser level tripod designed for building and decoration work in Kenya. It gives your laser level a stable, adjustable platform so you can project accurate horizontal and vertical reference lines without balancing the instrument on bricks, buckets or ladders.
Built from aluminium alloy, the stand is light enough to carry around site yet stiff enough to hold the laser steady. A standard 5/8" metal connector fits most line lasers, cross-line lasers, rotary lasers and other site instruments, while the telescopic legs and column set any working height between 0.45 m and 1.2 m. Rubber hoof pads on each foot protect finished floors and stop slipping on tiles, screed and polished surfaces.
Whether you are a fundi setting out tiles, a contractor fixing gypsum ceilings or a homeowner hanging cabinets, the Deli DL4161-2 makes laser levelling faster, safer and more accurate.
Key Features & Benefits
Aluminium Alloy Body
Corrosion-resistant, lightweight construction that is easy to carry between rooms and floors yet rigid enough for accurate readings.
5/8" Metal Connector
Durable metal thread – not plastic – for a secure, wobble-free fit with standard laser levels and site instruments.
0.45 – 1.2 m Telescopic Height
Extend the legs and central column to place the laser line exactly where you need it, from floor level to above worktop height.
Fine Height Adjustment
Top-mounted adjustment handle lets you raise or lower the laser in small steps to hit your exact reference mark.
Anti-slip Hoof Pads
Rubber feet grip tiles, screed and timber floors and protect finished surfaces from scratches.
Quick-lock Leg Clamps
Flip-lock clamps set each leg section quickly so you can level the stand on uneven site ground in seconds.
Full Technical Specifications
| Specification | Details |
|---|---|
| Brand | Deli |
| Model | DL4161-2 |
| Product Type | Horizontal Instrument Bracket / Laser Level Tripod Stand |
| Material | Aluminium alloy legs and column |
| Mounting Thread | 5/8" metal connector (standard laser level / surveying thread) |
| Working Height | 0.45 m – 1.2 m (telescopic) |
| Leg Design | Three telescopic legs with lock clamps |
| Height Adjustment | Telescopic legs plus central column with top adjustment handle |
| Feet | Rubber hoof pads (anti-slip, floor-protecting) |
| Compatible Instruments | Line lasers, cross-line lasers, 3D/4D green-beam lasers, rotary lasers and other 5/8" instruments (1/4" lasers with adapter) |
| Scope of Application | Elevating the laser level for horizontal and vertical measurement during construction and decoration |
| Packaging | Single unit in Deli branded carton |
Where to Use It
How to Use the Deli DL4161-2 Laser Level Tripod
- Unpack and inspect. Remove the bracket from the carton and check that all leg clamps, the hoof pads and the 5/8" connector are intact.
- Open the legs. Spread the three legs fully outward on firm, flat ground for the widest, most stable base.
- Set the rough height. Open the leg clamps, extend each leg section to the approximate height you need (0.45 m – 1.2 m) and close the clamps firmly.
- Level the stand. Adjust individual legs until the top plate sits roughly level – this keeps your laser within its self-levelling range.
- Mount the laser. Screw the laser level onto the 5/8" metal connector until it is snug. Do not overtighten. For 1/4" lasers, fit a 1/4"-to-5/8" adapter first.
- Fine-tune the height. Turn on the laser and use the top adjustment handle to raise or lower the line precisely onto your reference mark.
- Work with the line. Mark or install tiles, ceiling channels, cabinets or panels along the projected laser line. Re-check the mark if the stand is bumped.
- Pack away. Remove the laser first, retract the column and legs, wipe off dust and cement and store the stand in its box in a dry place.
Pro Tips & Safety Precautions
- Always place the tripod on a firm surface – avoid loose sand or soft soil without a solid base.
- Keep legs spread to their widest position before mounting the instrument.
- Never leave the laser mounted on a fully extended stand in busy walkways where it can be knocked over.
- Do not look directly into the laser beam or point it at other people's eyes.
- Clean cement, plaster and paint off the legs immediately so clamps keep sliding smoothly.
- Avoid dropping the stand – a bent leg or damaged connector affects accuracy.
Why Buy from Shabbiri Hardware?
- Trusted hardware and building materials supplier on Magadi Road since 1990
- Genuine Deli tools in stock at both Ongata Rongai and Tuala branches
- One-stop shop: laser tools, tiling accessories, gypsum, wall panels, flooring, plumbing, Sika, Akfix and Crown Paints
- Friendly advice on choosing the right laser level and accessories
- Delivery available across Nairobi, Rongai, Kiserian, Karen, Kitengela and nearby areas – call to arrange
Frequently Asked Questions
Which laser levels fit the Deli DL4161-2 tripod?
Any laser level, line laser or rotary laser with a standard 5/8" mounting thread. Lasers with a 1/4" thread can be used with a 1/4"-to-5/8" adapter.
How high does the stand go?
The telescopic legs and column give a working height from 0.45 m up to 1.2 m.
Is it suitable for outdoor site work?
Yes. The aluminium alloy body resists rust and the hoof pads grip well. On soft ground, place the feet on a firm board for stability.
Can I use it for tiling and gypsum ceiling work?
Absolutely – it is ideal for setting tile lines, ceiling channel heights, skirting levels and cabinet installation lines.
Where can I buy the Deli DL4161-2 in Nairobi?
At Shabbiri Hardware on Magadi Road – Ongata Rongai branch (opposite Hashi Petrol Station) and Tuala branch (past Nazarene University). Call 0741 042484 or 0745 554008.
Do you deliver?
Yes. Call or WhatsApp either branch to arrange delivery within Nairobi and surrounding areas.
Visit Our Branches
Two convenient branches on Magadi Road – walk in, call ahead or tap Get Directions to open Google Maps on your phone.
📍 Ongata Rongai Branch
Opposite Hashi Petrol Station
📍 Tuala Branch
Get Your Deli DL4161-2 Today
📞 0741 042484 | 📞 0745 554008
✉️ info@shabbirihardware.com | 🌐 www.shabbirihardware.com
Specifications
| Brand | Deli |
| Model | DL4161-2 |
| Category | Hand Tools |
| Availability | In stock |
| Sourced by | Shabbiri Hardware Kenya Limited |
