Fundi Fiberglass Folding Ladder FFL45-FRP — 4 x 5 Step
Why buy the fiberglass
Because the rails are pultruded FRP fiberglass and not aluminium, they do not conduct electricity — the correct choice for electrical, solar, CCTV and telecom work in Nairobi and countrywide.
Electrically non-conductive
Pultruded fiberglass side rails do not carry current the way aluminium stiles do. Standard practice for electricians, solar installers and telecom crews working on live low-voltage systems.
Weather & chemical resistant
FRP does not rust, corrode or soften. It shrugs off rain, coastal salt air, cement slurry, paint thinners, acids and fertiliser — ideal for sites, plants and farms.
Stiffer under load
Fiberglass rails flex noticeably less than aluminium at full extension, so the ladder feels planted at 5 m and stays comfortable for long overhead work.
Four locking hinges
Heavy steel multi-position hinges with spring-loaded lock pins snap positively into each angle and hold there — no creeping mid-job.
Fits any vehicle
Folds to roughly 1.5 m — it goes in a pickup bed, a van, a probox boot or on a roof rack. No need for a 6 m lorry to move a 6 m reach.
Replaces four ladders
Step ladder, extension ladder, stairway ladder and scaffold base in one purchase — less capital tied up and less kit to store.
Full technical specifications — Fundi FFL45-FRP
Nominal manufacturer figures for the 4 x 5 step fiberglass model. Small variations of a centimetre or two between production batches are normal; if a dimension is critical to your job, call us and we will measure the exact unit in stock.
| Specification | Detail |
|---|---|
| Identification | |
| Brand | Fundi |
| Model / Part number | FFL45-FRP |
| Product type | Articulated multipurpose folding ladder (combination ladder) |
| Configuration | 4 hinged sections x 5 steps per section = 20 rungs total |
| Range family | FFL43 (4x3), FFL44 (4x4), FFL44-FRP (4x4 fiberglass), FFL45 (4x5 aluminium), FFL45-FRP (4x5 fiberglass) |
| Materials & construction | |
| Side rails / stiles | Pultruded FRP fiberglass, non-conductive, UV-stabilised resin finish |
| Rungs / steps | Ribbed aluminium alloy, serrated anti-slip tread, riveted and swaged into the rails |
| Hinges | 4 x heavy-duty steel multi-position hinges with spring-loaded auto-locking pins |
| Feet | Non-marking non-slip PVC / rubber end caps (4 off, replaceable) |
| Finish / colour | Yellow fiberglass rails with natural aluminium rungs (typical Fundi FRP finish) |
| Dimensions | |
| Extended straight length | Approx. 5.70 m (about 18.7 ft) |
| Maximum working height — straight | Approx. 6.4 m (ladder length + average user reach) |
| A-frame (step ladder) standing height | Approx. 2.50 m |
| Maximum working height — A-frame | Approx. 3.2 m |
| Folded / transport size | Approx. 1.50 m x 0.46 m x 0.40 m (L x W x D) |
| Rung spacing (pitch) | Approx. 27 – 30 cm centre to centre |
| Ladder / rung width | Approx. 46 cm outside, giving a comfortable stance |
| Section length (each of 4) | Approx. 1.45 – 1.50 m |
| Performance & safety rating | |
| Maximum safe working load | 150 kg (330 lb) — user plus tools and materials combined |
| Duty standard | Built to EN 131 multipurpose ladder design and 150 kg duty rating |
| Electrical property | Fiberglass rails are non-conductive — suitable for work near live low-voltage circuits |
| Net weight | Approx. 22 kg (fiberglass is heavier than the ~17 kg aluminium FFL45) |
| Working positions | 7 — twin step ladder, straight/extension, 90° wall, stairway, scaffold base, low work bench, double-sided A-frame |
| Recommended set-up angle | 75° — the 1:4 rule (1 unit out for every 4 units of height) |
| Supply | |
| Supplied as | One complete assembled ladder — no assembly required, unfold and lock |
| Availability | In stock at both Shabbiri Hardware branches on Magadi Road (Ongata Rongai & Tuala) |
| Warranty | Manufacturer's warranty against manufacturing defects — current terms confirmed at the counter |
| Related accessories in stock | Scaffold planks, ladder stabiliser bars, replacement rubber feet, safety harnesses, tool belts |
Note on dimensions: ladder "4 x 5" describes the step count, not the metre length. Four sections of five rungs give 20 rungs and roughly 5.7 m of straight ladder — do not confuse it with a 4 m or 5 m single ladder.
How to use the FFL45-FRP — seven working positions from one ladder
Every position is set by releasing the spring pins on the hinges, swinging the section to the angle you want, and letting the pins snap home. Always hear and feel all four hinges lock before you load the ladder.
1. Twin step ladder (A-frame)
Lock the two centre hinges at the A position, sections 1+2 on one side and 3+4 on the other. Stands about 2.5 m for ceiling boards, gypsum, lighting and painting — free-standing, no wall needed.
2. Straight / extension ladder
Lock all four sections in line for a rigid 5.7 m straight ladder. Lean it at 75° against the wall for gutters, roofs, water tanks, aerials and second-floor work.
3. Stairway ladder
Shorten one leg by folding the bottom section back so the two legs sit at different heights. This is how you work safely on staircases, split levels and sloping ground.
4. 90° wall / corner position
Fold the top section vertical against the wall and keep the lower sections as the base. Lets you get in tight against a corner, a hedge or a parapet without over-reaching.
5. Scaffold base (with plank)
Two FFL45-FRP ladders in A-frame plus a certified scaffold plank between matching rungs gives a low working platform for long wall runs, plastering and cornice work.
6. Low work bench / trestle
Open the sections into a shallow M shape and drop a board across for a site bench — handy for cutting WPC panels, mitring skirting or laying out cable.
Step-by-step: setting up and climbing safely
Follow this sequence every single time. Most ladder injuries in Kenya come from set-up shortcuts, not from ladder failure.
Check the fiberglass rails for cracks, splinters or deep gouges, check all 20 rungs are tight, confirm the four rubber feet are present and not worn smooth, and work the hinge pins to be sure they spring back freely. Never use a ladder with a cracked rail — fiberglass fails suddenly, not gradually.
Set the feet on solid, dry, level ground. Do not stand the ladder on loose murram, wet tiles, a sand pile, blocks, bricks or a table. Where the ground slopes, use the stairway position instead of packing anything under one leg.
Stand the folded ladder upright, press the release pins, swing each section to the position you need and release the pin so it snaps into the hole. Push and pull each joint to confirm it is locked before any weight goes on it.
Leaning against a wall, the base goes one metre out for every four metres of height (a 75° angle). Too steep and it tips backwards; too shallow and the feet slide out.
When climbing onto a roof, slab or tank, the ladder must project about one metre (three rungs) above the landing point so you have something to hold while stepping off.
Above three metres, tie the top stiles off to a fixed point or have a second person foot the ladder. On smooth polished floors, add a rubber mat or brace the feet against a block.
Two hands and one foot, or two feet and one hand, at all times. Face the ladder going up and coming down. Carry tools in a belt or hoist them on a rope — never in your hands.
If you have to lean out past the stiles, come down and move the ladder. Over-reaching is the single most common cause of ladder falls.
Release the pins, fold the sections back together, and store the ladder flat or hung horizontally on brackets in a dry store. Keep fiberglass out of permanent direct sun to protect the resin surface.
Safety: do this, never do that
✅ Always do
- Confirm all four hinges are locked before loading.
- Keep the total load — you plus tools — under 150 kg.
- Use the fiberglass model for any work near live circuits.
- Wear clean, dry, closed shoes with grip.
- Keep the rails clean; wipe off cement, oil and paint after the job.
- Have a second person foot the ladder on windy or busy sites.
- Replace worn rubber feet immediately — we stock spares.
⛔ Never do
- Never stand on the top two rungs or on the hinge caps.
- Never let two people climb the same side at once.
- Never move or "walk" the ladder while standing on it.
- Never use it in a strong wind or a thunderstorm.
- Never treat any ladder as certified live-line HV equipment.
- Never repair a cracked fiberglass rail with tape or resin — retire the ladder.
- Never leave a ladder standing unattended on a public walkway.
Who buys the FFL45-FRP in Nairobi
This is the ladder we hand over most often to contractors working on Magadi Road, Rongai, Kiserian, Ngong, Karen, Kitengela and across Nairobi.
Fiberglass vs aluminium — pick the right one
| Comparison | FFL45-FRP (fiberglass) | FFL45 (aluminium) |
|---|---|---|
| Electrical safety | Non-conductive rails — safe near live LV circuits | Conducts electricity — keep away from live work |
| Weight | Approx. 22 kg | Approx. 17 kg — easier to carry alone |
| Stiffness at full height | Very rigid, minimal flex | More spring at 5 m |
| Corrosion / chemicals | Excellent — no rust, resists acids and cement | Good, but pits with cement and salt over time |
| Price | Higher — the safety premium | Lower — best value for general building |
| Best for | Electrical, solar, telecom, plant maintenance | Masonry, painting, general construction |
Frequently asked questions
What does "4 x 5 step" actually mean?
Four hinged sections with five rungs on each — 20 rungs in total. The four sections articulate on locking hinges, so the same ladder becomes an A-frame step ladder, a straight 5.7 m ladder, a stairway ladder or a scaffold base. It is a step count, not a length in metres.
Is a fiberglass ladder really safe for electrical work?
The FRP rails do not conduct electricity the way aluminium does, which is why electricians, solar installers and telecom crews specify fiberglass for work near live low-voltage circuits. Keep the rails clean and dry — dirt, moisture and metallic dust on the surface reduce the benefit. No ladder replaces certified live-line equipment and proper isolation procedure on high-voltage systems.
How high can I reach with it?
Straight and fully extended it is about 5.7 m long, giving roughly 6.4 m of safe working height for an average user. As an A-frame it stands about 2.5 m, giving about 3.2 m of working height.
How much weight can it carry?
150 kg maximum, to EN 131 duty rating — that is you plus your tools and materials together. Budget roughly 120 kg of body weight and 30 kg of tools.
Will it fit in my car?
Folded it is about 1.5 m long, so it fits a pickup bed, a van, most station wagons with the seats down, or a roof rack. That is the main advantage over a 6 m single ladder.
Do you deliver outside Ongata Rongai?
Yes. We deliver across Rongai, Tuala, Kiserian, Ngong, Karen, Langata, Kitengela, Kajiado, Nairobi and countrywide through our transport partners. Call 0741 042484 or 0745 554008 for a delivery quotation.
Do you offer trade or bulk pricing?
Yes — contractors, hardware resellers, schools, hotels and facility teams buying multiple units get trade pricing. Send your requirement to info@shabbirihardware.co.ke or WhatsApp us and we will issue a formal quotation.
Do you install or hire out ladders?
Shabbiri Hardware is a supply-only business — we sell the ladder and stock the accessories. We are happy to share contacts of independent installers and contractors who work in the area.
What else should I buy with it?
Most customers add a certified scaffold plank for the scaffold position, a spare set of rubber feet, a tool belt and a safety harness for roof work. All are stocked at both branches.
Visit Us — Both Branches on Magadi Road
See the Fundi FFL45-FRP ladder before you buy. Open Mon–Sat, 8am–6pm. Call 0741 042484 or 0745 554008.
Ongata Rongai — Main Store
Magadi Road, opposite Hashi Petrol Station
Tuala Branch
Magadi Road, past Africa Nazarene University
Get a Price on the Fundi FFL45-FRP Today
Call, WhatsApp or email for current pricing, trade rates on quantity, and quotations on letterhead.
