Home / Screws / Self Drilling Screws Truss Head 1 Inch (25mm) – Zinc Plated Wafer Head Tek Screws, 500pcs Packet
Self Drilling Screws Truss Head 1 Inch (25mm) – Zinc Plated Wafer Head Tek Screws, 500pcs Packet

Self Drilling Screws Truss Head 1 Inch (25mm) – Zinc Plated Wafer Head Tek Screws, 500pcs Packet

KSH 1,500/ packet
In stock
About this product
Self Drilling Truss Head Screws 1" 500pcs | Nairobi Kenya

Self Drilling Screws Truss Head 1" (25mm) – 500pcs Packet

Zinc plated truss (wafer) head tek screws that drill, tap and fasten in one step. The go-to screw for metal stud partitions, gypsum ceilings and light gauge steel work across Nairobi and Kenya.

Drill point – no pre-drilling Low-profile wide head Phillips drive 500 pcs per packet

Product Overview

The 1 inch truss head self drilling screw (SDS) has a built-in drill tip that cuts its own hole in steel, then forms its own thread as you drive it. There is no need to drill a pilot hole first, so fixing goes faster and holes line up perfectly.

Its wide, flat, low-profile truss head spreads load over a bigger area and sits almost flush with the surface. That is exactly why fundis use it to join metal studs to tracks in gypsum partitions — the head does not bulge under the board, so gypsum lies flat and finishes cleanly.

Packed 500 pieces per packet, ideal for contractors, drywall installers, fabricators and DIY projects. Available at Shabbiri Hardware, Magadi Road – Ongata Rongai and Tuala branches.

Technical Specifications

ProductSelf Drilling Screw (SDS / Tek Screw), Truss Head
Length1 inch (approx. 25 mm)
Head typeTruss / wafer head – wide, flat, low profile
Drive typePhillips cross recess (PH2 bit)
Point typeSelf drilling drill point (tek point)
MaterialHardened carbon steel
FinishZinc plated (silver / bright) for corrosion resistance indoors
ThreadFine machine-type thread for steel
Suitable base materialsLight gauge steel, metal studs & tracks, sheet metal, aluminium, galvanised steel
Recommended toolElectric drill / screwdriver with clutch, PH2 bit
Packing500 pieces per packet
Best environmentIndoor and sheltered areas

Diameter and drilling capacity vary by manufacturer batch — please check the packet or ask our branch team to confirm the gauge for your steel thickness.

Key Features & Benefits

Drill, tap and fasten in one actionSaves time and labour — no separate drilling, no misaligned holes.
Low-profile wafer headSits flat so gypsum board, cladding or panels lie smooth over the joint.
Wide bearing surfaceGrips thin metal firmly and resists pull-through better than small pan heads.
Zinc platedProtects against rust in indoor and covered conditions.
Bulk 500pcs packetEnough for large partition and ceiling jobs, better value than loose screws.

Common Applications

  • Joining metal studs to floor and ceiling tracks in gypsum partitions
  • Fixing gypsum ceiling furring channels and main channels together
  • Light gauge steel framing and steel-to-steel connections
  • Fixing sheet metal, flashing trims and metal brackets
  • Ducting, cable trays and electrical boxes
  • Aluminium frames, shopfitting and display units
  • General fabrication, workshop and DIY projects

How to Use

  1. Choose the right length. The 1" screw suits joining two thin metal layers such as stud and track. The drill tip should fully pass through the steel before the threads engage.
  2. Fit a PH2 bit. Use a cordless drill or screwdriver with a clutch. A magnetic bit holder keeps the screw steady.
  3. Mark and clamp. Mark your fixing points and hold the metal parts tightly together so no gap forms between layers.
  4. Start straight. Hold the screw at 90° to the surface. Apply firm, steady pressure and run the drill at medium speed — let the drill point do the cutting.
  5. Drive home. Once the tip breaks through, the threads pull the screw in. Stop as soon as the head sits flat against the surface.
  6. Do not over-tighten. Over-driving strips the thread in thin steel. Set the clutch low and increase only if needed.
  7. Check and continue. Confirm each screw is firm, then continue along the stud or channel at your planned spacing.

Important Tips & Safety

Not for roofing mabati: truss head screws have no sealing washer and can allow leaks. For iron sheets, use hex head roofing screws with a rubber (EPDM) washer.
Not for thick steel: for heavy sections, use a longer drill point screw or pre-drill.
Not for timber framing: use wood screws or wing-tip self drilling screws for wood-to-metal.
Protect yourself: wear safety glasses — drilling throws off hot metal swarf.

Frequently Asked Questions

What are truss head self drilling screws used for?

They fix metal to metal without pre-drilling — mainly metal studs to tracks in gypsum partitions, ceiling channels, light steel framing, sheet metal, ducting and electrical boxes.

Can I use these screws for mabati roofing?

Not recommended. They have no sealing washer, so water can get in. Use hex head roofing screws with an EPDM washer for iron sheets.

Do I need to drill a hole first?

No. The drill point cuts its own hole in thin steel. Simply drive the screw with a drill and PH2 bit.

How many screws are in one packet?

Each packet has 500 pieces.

Do you deliver?

Yes, delivery is available on request within Nairobi and countrywide, plus free pickup at our Rongai and Tuala branches.

Where can I buy self drilling screws near me in Nairobi?

Visit Shabbiri Hardware on Magadi Road — Ongata Rongai branch (opposite Hashi Petrol Station) or Tuala branch (past Nazarene University).
