Stone Coated Valley Tray for Roofing Tiles – Nairobi, Kenya
Valley Tray for Stone-Coated Roofing Tiles in Nairobi, Kenya
The stone-coated valley tray is the channel that sits where two roof slopes meet, carrying heavy rainwater safely down to the gutter. Made from aluminium-zinc coated steel and finished with natural stone chips, it matches stone-coated roofing tiles in colour and texture while keeping your roof valley leak-free for years.
Technical Specifications
| Product | Valley Tray / Valley Flashing for stone-coated roofing |
|---|---|
| Category | Roofing Sheets & Roofing Accessories |
| Base material | Hot-dipped aluminium-zinc (Aluzinc / Galvalume) coated steel |
| Surface finish | Natural stone chips bonded with acrylic resin and sealed with a UV-resistant clear glaze |
| Profile | Flat-bottom channel with raised side returns (water stops) on both edges |
| Typical length | Approx. 2 metres per piece (confirm exact length with branch) |
| Sheet thickness | Approx. 0.40 mm – 0.50 mm steel core |
| Colours | Charcoal / black, tile red, maroon / brown, green and other stone-coated shades |
| Compatible with | Stone-coated roman, shingle, milano, bond and classic tile profiles |
| Fixing | Roofing nails or self-drilling screws onto valley boards / battens |
| Overlap | Approx. 150 mm between consecutive pieces |
| Key properties | Rust resistant, non-fading, fire resistant, rain-noise reducing |
| Selling unit | Per piece |
| Availability | Ongata Rongai and Tuala branches, Magadi Road |
Features & Benefits
Fast Water Run-off
Roof valleys collect water from two slopes at once. The wide channel moves this heavy flow quickly to the gutter, even in Nairobi's long rains.
Built to Resist Rust
The Aluzinc coating protects the steel core from corrosion, giving a far longer life than plain galvanised valley sheets.
Seamless Look
Stone chips match the colour and texture of your stone-coated tiles, so the valley blends neatly into the roof.
Side Water Stops
Raised edges hold water inside the channel and stop wind-driven rain from creeping under the tiles.
Quiet Under Rain
The stone-chip layer softens the sound of rain compared with bare metal flashing.
Easy to Install
Lightweight pieces are simple to lift, cut and overlap, saving time for roofing fundis.
How to Install a Valley Tray
- Measure the valley. Measure from the eaves to the ridge along the valley line and work out how many pieces you need, allowing about 150 mm overlap per joint.
- Prepare the valley base. Fix valley boards or extra battens on both sides of the valley rafter so the tray has full, firm support along its length.
- Lay the underlay. Run waterproof roofing underlay down the valley before fitting the tray for an extra layer of protection.
- Start at the bottom. Place the first valley tray at the eaves, extending slightly over the fascia so water drops straight into the gutter.
- Overlap upwards. Lay each next piece on top of the one below, working up towards the ridge, so water always flows over joints and never into them.
- Fix along the edges only. Nail or screw through the outer side returns, never through the centre channel where water runs.
- Cut and fit the tiles. Mark and cut the stone-coated tiles along the valley line, leaving an open water channel of about 100 mm – 150 mm in the middle.
- Seal and touch up. Seal cut tile edges and joints with a suitable roofing sealant, and touch up any cut edges with stone-chip touch-up kit or matching paint.
Where to Use It
- Residential houses and maisonettes with stone-coated roofing
- Hip and valley roofs, L-shaped and T-shaped roof designs
- Apartments, schools, churches and commercial buildings
- Roof extensions where a new roof meets an existing slope
- Re-roofing and repair of leaking valleys
Why Buy from Shabbiri Hardware?
Shabbiri Hardware Kenya Limited has supplied builders, contractors and home owners since 1990. We stock stone-coated roofing tiles together with valley trays, ridges, hip caps, barge boards and PVC gutter systems, so you can buy your full roofing package in one place.
- Two convenient branches along Magadi Road
- Genuine quality roofing accessories
- Delivery within Nairobi and countrywide on request
- Contacts of trusted independent roofing installers available
Frequently Asked Questions
What is a valley tray used for?
It lines the valley where two roof slopes meet and channels rainwater down to the gutter, preventing leaks at the weakest point of the roof.
Can I use a valley tray with iron sheets?
This stone-coated valley tray is designed for stone-coated tiles. For iron sheets or box profile roofs, ask our team for a matching plain valley flashing.
How many valley trays do I need?
Divide the valley length by the effective length of one piece after overlap. Share your roof plan with us and we will help you calculate.
Which colours are available?
We stock popular stone-coated colours such as charcoal, red, brown and green. Contact your nearest branch to confirm current stock.
Do you install roofs?
We are supply-only, but we can share contacts of experienced independent roofing installers.
